CHAPTER 11. Service standards and other information

SECTION 1. SERVICE STANDARDS.

Part names and

inspection items

Nominal

dimensions

Standard value

for reassembly

Usable limits Service instructions

and remarks

1.ENGINE ACCESSORIES(CHAPTER 3)

1) RADIATOR

Coolant capacity 2.38 ℓ Radiator alone

5.2 ℓ Whole cooling system

Radiator cap valve operating pressure

0.9 ±0.15㎏f·㎠

2) AIR CLEANER

Element capacity

Rated intake air : 2.6 ㎡

Air passing resistance : 340㎜Aq

or less Filtering efficiency

Total : 99.9% or more

Cyclone : 55% or more

Dust holding capacity : 180g or

OUTER ELEMENT

1. Clean or wash the element after 100 hours of operation.Replace a damaged on or one which

has been used more than 500 hours.

a.Cleaning (when dust is dry)

Apply compressed air of 7Kgf/㎠ or lower to the inside of the element to blow dust outwards.

Never strike element to dust.

b.Washing(when dust is wet or oily)

Dissolve element cleanser or neutral detergent of good quality in water.Keep the element

immersed in the solution about 30 minutes and then wash it by shaking gently.

-Then,rinse it in fresh water;Water pressure should be less than 2.8 Kgf/㎠.

-Leave the washed element in a shaded,well-ventilated place to dry itself.

Never force-dry heat or compressed air.

2. An element which has been washed five times should be replaced with a new one.

3. When the tractor is used in dusty situation,Inspect the element everyday and clean if necessary

11-1

TYM T233 HST User Manual
