TYM T233 HST User Manual

2) PTO DRIVE SYSTEM
MODEL T233HST/T273HST
T233HST/T273HST
Speed shift range Engine rated rpm: 2700 rpm
Reduction
ratio
Main speed shift HST
Speed range shift L (Low)
H (High)
0.53 (19/21 * 17/29)
1.49 (19/21 * 28/17)
Drive pinion-Wheel gear 0.03 (9/55 * 12/71)
Operation
methods
Main speed shift Pedal - RH
Speed range shift Side shift - LH
Oil
capacity
Transmission case Recommended Oil THF500
Capacity 17 ℓ
SECTION 2. SPECIFICATIONS
1. WHEEL DRIVE SYSTEM
TYPE INDEPENDANT
CLUTCH Multiple Wet Disk
Rear PTO
Speed shift range 1
Reduction ratio 0.21 (11/53)
PTO shaft speed 540 @ Engine 2,601rpm
PTO shaft size Φ35 mm, 6 straight splines
Rotation direction CW viewed from the rear
Mid PTO
(optional)
Speed shift range 1
Reduction ratio 0.77 (11/53*41/32*32/11)
PTO shaft speed 2000 @ Engine 2,585 rpm
PTO shaft size Φ25 mm, 10 straight splines
Rotation direction CW viewed from the rear
PTO clutch Type Wet, multi-disc, hydraulic-operated clutch
Number of clutch plates
Friction 6, Plate 5
Used oil THF500 (In common with transmission oil)
