112
Starting and driving
Towbars
The connector pin must be cleaned and
lubricated with grease regularly. When ball
hitch with vibration damper is used there is
no need to grease the connection pin.
If the car is equipped with a detachable tow
hitch the installation instructions for installing
the connector pin must be followed closely.
See page 114.
WARNING!
Ensure that the trailer's safety cable is
secured to the correct mounting.
WARNING!
If the car is equipped with a Volvo
detachable towbar:
• Follow the installation instructions for
the connector pin carefully.
• The connector pin must be locked by
the key before moving off.
• Check that the indicator window is
showing green.
Towing bracket
Trailer cable
An adapter is required if the car's towing
bracket has a 13-pin electrical connector and
the trailer has a 7-pin connector. Use a Volvo
approved adapter cable. Make sure that the
cable does not drag on the ground.
Specifications
Distance A
Fixed towbar: 1100 mm (43 inches)
Detachable towbar: 1100 mm (43 inches)
Maximum ball pressure: 75 kg (165 lbs)
