154
Maintenance and service
Direction indicator
1. Twist the bulb holder anti-clockwise and
remove it.
2. Press the bulb inwards, turn it
anticlockwise and remove it from the
bulb holder.
3. Replace with a new bulb and reinstall
the bulb holder in the lamp housing.
Side marker lamps
1. Twist the bulb anticlockwise, pull it out
and replace the bulb.
2. Reinstall the bulb holder. It can only be
fitted in one position.
Fog lamps
1. Switch off all lights and turn the ignition
key to position 0.
2. Remove the panel around the lamp
housing.
3. Unscrew both the torx screws in the
lamp housing and take out the lamp
housing.
4. Remove the connector from the bulb.
5. Turn the bulb anticlockwise and pull it
out.
6. Locate the new bulb in its seat and turn
clockwise.
7. Connect the connector to the bulb.
8. Secure the lamp housing using the
screws and press the panel back.
