Maintenance and service
Removing the bulb holder
All front bulbs (except for fog lamps) are
replaced by disconnecting and removing the
lamp housing via the engine compartment.
WARNING!
If the car is equipped with Bi-Xenon
headlamps, all work on the headlamps
must be carried out by a Volvo
workshop.
Bi-Xenon headlamps require great care
due to the high voltage element.
Replacing front bulbs
1. Remove the ignition key and turn the
light switch to position 0
2. Pull up the lamp housing's locking pin
(1)
3. Pull the lamp housing to one side and
then forwards (2)
4. Disconnect the connector
5. Lift out the lamp housing and place it on
a soft surface so as not to damage the
lens.
Installing the lamp housing:
1. Install the lamp housing in reverse order.
Check that the lock pin is correctly
situated.
2. Check the lighting.
NOTE! The lamp housing must be connected
and securely positioned before turning on the
lights or before inserting the ignition key in
the ignition.
Cover with lock catches
Dipped beam
1. Remove the entire lamp housing.
2. Move the lock catches to one side and
remove the cover.
3. Release the spring clamp holding the
bulb. First push to the right so that the
spring clamp releases, then out and
down.
4. Pull out the bulb.
5. Remove the connector from the bulb.
