41
Instruments and controls
1. Headlamp levelling
The headlamp height is adjusted using this
control. This is used when the car is so
heavily laden that it affects the height of the
beams.
• Normal beam height - move the control
upwards (0).
• Lowered beam height - move the control
downwards.
Cars with Bi-Xenon lighting (option) have
automatic headlamp levelling.
Lighting panel
2. Headlamps and position/
parking lamps
All lighting off.
Cars with daytime running
lights (certain countries)
Dipped beam lights automatically
when the ignition key is switched to the
driving position (II) and cannot be switched
off. Before trips to certain countries, the
daytime running lights can be deactivated.
Contact a Volvo workshop. Front and rear
parking lamps, number plate lighting and
instrument lighting are lit at the same time as
dipped beam.
Position/parking lamps
Front and rear position/parking
lamps as well as number plate
lighting and instrument lighting.
Main and dipped beam
Ignition key in position II:
Headlamps (plus front and rear
parking lamps, number plate
lighting and instrument lighting)
are lit.
NOTE! The light switch must be turned to
position II to switch on the main beam.
However, it is possible to flash the main beam
in all positions, even when the key is not in the
ignition switch. See also page 43.
3. Instrument lighting
Manual adjustment:
• Brighter illumination - move the control
upwards.
• Weaker illumination - move the control
downwards.
Automatic control:
A twilight sensor automatically adjusts the
brightness of instrument illumination.
4. Fog lamps (option)
Ignition key in position II:
• Press the button.
The fog lamps light in combination with
the position/parking lamps and main/
dipped beam. The LED in the button is
lit while the fog lamps are on.
NOTE! In some countries, dipped beam or
main beam may not be used in combination
with front fog lamps.
5. Fuel filler flap
• Press the button to open the flap
covering the fuel cap.
