5.2 TECHNICAL DATA
Dimensions:
Height 136 mm; 5.35 inch
Width 270 mm; 10.63 inch
Depth (without operating elements) 200 mm; 7.87 inch
Weight 3.3 kg; 7.28 lb
Electrical:
Mains (AC) input terminal 90 VAC–250 VAC
Frequency 47 Hz–63 Hz
Input power maximum 120 W
Mains (AC) output terminal Vibrator motor maximum 70 W
Output voltage spray gun maximum 22 Vpp
Output current spray gun Max. 0.9A
High voltage 10-100 kV (adjustable in 1 kV steps)
Corona current limitation 5 µA - 120 µA (adjustable in 1 µA steps)
Tribo current measuring range 0 µA - 15 µA
Tribo current limitation 0 µA - 5 µA (adjustable in 0.1 µA steps)
Tribo current cut o greater than 12 µA
(ATEX: switching o of the unit)
Ex identication:
according to EN (ATEX, EN) II 3(2)D
according to Class & Division (North
America)
Class II, Division 2, Group E, F and G
Pneumatic:
Input air pressure 0.6–0.8 MPa; 6–8 bar; 87–116 psi
Air ow maximum 15 m³/h
Sum of dosing and feed air 1–6 m³/h
Gun air 0.05–4.0 m³/h
Required compressed air quality as per
ISO8573.1, 2010
6.5.2
Connection hose diameter 8 mm; 0.315 inch
Ambient conditions:
Operating temperature range 5–40 °C; 41–104 °F
