7 Wiring diagrams BlueCool S Series
22
7 Wiring diagrams
Fig. 14 Electrical wiring
1
3
2
45
6
7
8
9
10
11
1 = Fan motor
2=Power supply
3 = Low-pressure switch
4 = High-pressure switch
5 = Cabin temperature sensor
6 = Digital display
7 = PC diagnosis via USB
8 = Evaporator temperature sensor
9 = 4-way reverse valve
10 = Sea water pump
11 = Compressor (for models S8 to S20)
