92 A Appendix
9. Tighten the two screws to secure the control
board in place.
10. Connect the connector conversion cable to
the Parallel Port connector.
Note
• Connect the parallel cable to the connector on other end
of the connector conversion cable. For more
information, refer to “Connecting a cable” (P. 22).
11. Connect the power cord to the printer.
Press the <|> side of the printer's power
switch to turn on the power.
12. Print the [Configuration Report] and confirm
that [Parallel] is included in the
[Communication Settings] section.
Refer to
• List printing procedure: “Printing a Report/List” (P. 36)
Parallel Port installation is now complete.
Installing the TC/SC Font
ROM
This section describes how to install the TC/SC
Font ROM on the printer.
1. Switch the power off by pressing the < >
side of the power switch.
2. Unplug the power cord from the power outlet
and the printer.
3. Loosen the two screws on the back right side
of the printer.
TC/SC Font ROM
To Next Page
