Xerox WorkCentre PE16 Service Manual

7-20
Troubleshooting
WorkCentre PE16
Service Manual
July 2003
7.4.8 Defective FAX RECEIVE (4)
• Description The received data is reduced by more than 50% in the printing.
7.4.9 Defective Automatic Receiving
• Description The automatic receiving function is not working.
Check and Cause Solution
Check the FAX status of the sending side. After checking the data of the sending side, correct the
FAX of the sending side.
Check and Cause Solution
1. Check if the RECEIVE Mode is TEL MODE or FAX
MODE.
1. If the RECEIVE Mode is set to the TEL MODE, reset it
to the FAX MODE.
2. After the RECEIVE mode is changed to FAX MODE, if
it cannot receive, replace the LIU PBA and the Main
PBA in sequence.
