Xerox WorkCentre PE16 Service Manual

2
2
2-1
Reference Information
Service Manual
WorkCentre PE16 July 2003
2. Reference Information
This chapter provides reference information for this service manual consisting of the tool list, a list
of acronyms and abbreviations, and examples of test patterns.
2.1 Tool for Troubleshooting
The following tools are recommended for perfomance of the troubleshooting functions described in this service manual.
DVM(Digital Volt Meter)
Standard: Indicates more than 3 digits.
1
Tweezers
Standard: For general home use, small
type.
2
Software(Driver) installation CD
ROM
6
Cotton Swab
Standard : For general home use, for
medical service.
4
Cleaning Equipment IPA
(Isopropyl Alcohol) dry cloth or a
liquid neutral detergent.
5
Driver
Standard : "-" type, "+" type (M3 long, M3
short, M2 long, M2 short).
3
