6-12
ALIGNMENT & ADJUSTMENTS
Service
Manual
July 2003 WorkCentre PE16
6.4.3 Data Setup
SEND LEVEL
You can set the level of the transmission signal. Typically, the Tx level should be under -12 dBm.
Caution : The Send Fax Level is set for optimum performance when shipped from the factory. Never
change settings arbitrarily.
MODEM SPEED
You can set the maximum modem speed.
Modem speed is automatically set to the lower speed when communicating with a slower speed modem
since communication is done using the standard of lowest speed unit to ensure proper
transmission/reception. Speed is best set 33.6Kbps as the default setting.
ERROR RATE
When the error rate is about to exceed the set value, the Baud rate automatically adjusts to 2400 bps.
This ensures that the error rate remains below the set value.
You can select the rate between 5% and 10%.
CLEAR ALL MEMORY
The function resets the system to the factory default settings.
This function is used to reset the system to the initial values when the product is functioning abnor-
mally. All the values are returned to the default values, and all the information, which was set by
the user, will be erased.
< Method >
1. Select the [MEMORY CLEAR] in the TECH MODE.
2. Push the ENTER button.
3. Select your country. (There are four country groups. Refer to the table below.)
4. Push the ENTER button then it will clear all memory.
NOTICE : Always perform a memory clear after replacing the main board. Otherwise, the system
may not operate properly.
Country Group USA/Canada UK Russia Southafrica
USA/Canada UK Russia Southafrica
Mexico Germany india
Brazil France Oman
Italy Poland
Spain Bangladesh
Austria Kuwait
Netherlands Moroco
Belgium Algeria
Country Portugal Pakistan
Sweden UAE
Norway Bahrain
Denmark Srilanka
Finland SaudiArabia
Switzerland Chile
Greece Peru
Ireland Argentina
Turkey Hungary
Romania
Bulgaria
Czech
To Next Page
