KCU105 Board User Guide www.xilinx.com 107
UG917 (v1.4) September 25, 2015
Appendix C: System Controller
These mezzanine cards can be attached to the J22 HPC or J2 LPC expansion ports on the
KCU105 board. Table C-3 shows the accessible clock resources on each FMC module.
FMC Menu Options
KCU105 System Controller
- FMC Menu-
1. Set FMC XMxxx CLOCKS
2. Read FMC HPC IIC EEPROM
3. Read FMC LPC IIC EEPROM
4. Set FMC VADJ to 1.8V
5. Set FMC VADJ to 1.5V
6. Set FMC VADJ to 1.2V
7. Set FMC VADJ to 0.0V
0. Return to Main Menu
Select an option
Identify the FMC module types plugged on to the KCU105 board, and which FMC connector
is associated - the left J22 HPC or right J2 LPC. The examples shown in this section reflect
the particular FMC installed at the KCU105 board J22 HPC FMC connector.
Table C-3: FMC Module/Board
Xilinx FMC Module/Board Clock Source #1 Clock Source #2
XM101 Si570 Si570
XM104 Si570 Si5638
XM105 Si570 n/a
XM107 Si570 n/a
KCU105 Base Board Si570 Si5328
