KCU105 Board User Guide www.xilinx.com 6
UG917 (v1.4) September 25, 2015
Chapter 1
KCU105 Evaluation Board Features
Overview
The KCU105 evaluation board for the Xilinx
®
Kintex
®
UltraScale
™
FPGA provides a hardware
environment for developing and evaluating designs targeting the UltraScale
XCKU040-2FFVA1156E device. The KCU105 evaluation board provides features common to
many evaluation systems, including a DDR4 component memory, a high definition
multimedia interface (HDMI
™
), two small form-factor pluggable (SFP+) connectors, an
eight-lane PCI Express
®
interface, an Ethernet PHY, general purpose I/O, and two UART
interfaces. Other features can be added by using VITA-57 FPGA mezzanine cards (FMCs)
attached to the low pin count (LPC) FMC and high pin count (HPC) FMC connectors.
KCU105 Evaluation Board Features
The KCU105 evaluation board features are listed here. Detailed information for each feature
is provided in Feature Descriptions.
• Kintex UltraScale XCKU040-2FFVA1156E device
•Zynq
®
AP SoC XC7Z010 based system controller
• 2 GB DDR4 component memory (four [256 Mb x 16] devices)
• Dual 256 Mb Quad serial peripheral interface flash memory (Dual Quad SPI)
• Micro secure digital (SD) connector
• USB JTAG interface via Digilent module with micro-B USB connector
• Clock sources:
°
Si5335A quad fixed frequency clock generator (300 MHz, 125 MHz, 90 MHz,
33.333 MHz)
°
Si5328B clock multiplier and jitter attenuator (8 kHz - 808 MHz)
°
Si570 I2C programmable LVDS clock generator (10 MHz - 810 MHz)
°
Subminiature version A (SMA) connectors (differential)
• 20 GTH transceivers (five Quads)
°
FMC HPC connector (eight GTH transceivers)
Send Feedback
