KCU105 Board User Guide www.xilinx.com 57
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
Status and User LEDs
Tab le 1- 20 defines KCU105 board status and user LEDs.
Table 1-20: KCU105 Board Status and User LEDs
Reference Designator Description
DS2 INIT
DS3 OR'D POWER GOOD
DS4 CP2105 DUAL UART GPIO0_ECI_IO
DS5 CP2105 DUAL UART GPIO0_SCI_IO
DS6 GPIO_LED_1
DS7 GPIO_LED_0
DS8 GPIO_LED_2
DS9 GPIO_LED_5
DS10 GPIO_LED_4
DS14 UTIL_3V3_PGOOD
DS15 MGTAVCC_PGOOD
DS16 VCC1V2_PGOOD
DS17 MGTAVTT_PGOOD
DS18 VCCAUX_PGOOD
DS19 VADJ_1V8_PGOOD
DS21 VCCINT_PGOOD
DS23 VCCBRAM_PGOOD
DS24 VCC1V8_PGOOD
DS25 MGTVCCAUX_PGOOD
DS26 12V ON
DS27 SYS_2V5 ON
DS28 SYS_1V8 ON
DS31 GPIO_LED_7
DS32 GPIO_LED_6
DS33 GPIO_LED_5
DS34 DONE
DS36 DDR4 VTT ON
DS37 CP2105 DUAL UART GPIO1_SCI_IO
DS38 CP2105 DUAL UART GPIO1_ECI_IO
DS42 SYSCTLR INIT
DS43 SYSCTLR STATUS
DS44 SYSCTLR DONE
