Xilinx KCU105 User Manual

KCU105 Board User Guide www.xilinx.com 58
UG917 (v1.4) September 25, 2015
Chapter 1: KCU105 Evaluation Board Features
User I/O
[Figure 1-2, callouts 23-26, 40]
The KCU105 board provides these user and general purpose I/O capabilities:
• Eight user LEDs (callout 23)
°
GPIO_LED[7-0]: DS31, DS32, DS33, DS10, DS19, DS8, DS6, DS7
• Five user pushbuttons and CPU reset switch (callout 24)
°
GPIO_SW_[NESWC]: SW10, SW9, SW8, SW6, SW7
°
CPU_RESET: SW5
• 4-position user DIP Switch (callout 25)
°
GPIO_DIP_SW[3:0]: SW12
• User Rotary Switch (callout 40)
°
ROTARY_PUSH, ROTARY_INCA, ROTARY_INCB: SW13
• User SMA (callout 26)
°
USER_SMA_GPIO_P, USER_SMA_GPIO_N: J36, J37
DS45 SYSCTLR ERROR
DS46 SYS_1VO ON
DS49 5V ON
EPHY P3 GREEN LED ENET PHY LINK1000
EPHY P3 YELLOW LED ENET PHY TX
Table 1-20: KCU105 Board Status and User LEDs (Cont’d)
Reference Designator Description
Send Feedback
