Appendix C: System Controller
CONFIG Menu
The system controller CONFIG menu is used to configure the KCU105 UltraScale FPGA from
a micro-SD card. One of sixteen bitstreams can be selected for use by the configuration
engine by setting a binary encoded value on the system controller mode DIP switch SW15
positions 1 - 4 (M3, M2, M1, M0) prior to board power up. See FPGA Configuration, page 13.
Once the board is powered up or when the system controller POR pushbutton (SW14) is
pressed, the system controller CONFIG Menu can also be used to select the micro-SD card
bitstream.
CONFIG Menu Options
KCU105 System Controller
- CONFIG Menu-
1. Configure UltraScale FPGA from microSD Card
0. Return to Main Menu
Select an option
Option 1: Configure UltraScale FPGA from microSD Card
Enter a Bitstream number (0-15):
0
Info: Xilinx.sys opened
Info Configuration definition file "kcu105d/set0/config.def" opened
Info: Clock divider is set to 2
Info: Total 1 device(s) in the chain
Info: Total 1 configuration target(s) in the chain
Info: Target device ID code: 0x3822093
Info: Target device DNA code: 0xD4B3A5820E041
Info: Configuring target(s)...
Info: Bitfile "kcu105d/set0/ipi_app.bit" opened
...10%...20%...30%...40%...50%...60%...70%...80%...90%...100%
Info: Target Done is high
Info: Target Init_b is high
Configuration completed successfully!
Option 0: Return to Main Menu
This option returns to the menu level above.
