XO FLEX – Instructions for use Operation
43
Figure 54 – Manual start of (1) cuspidor and (2) cup filler
Activate (2) – see Figure 54 – for less than one second and the glass fills with the pre-configured
amount of water.
Activate (2) again for less than one second to stop automatic filling.
If (2) is activated for more than one second, water fills the cup while the button is activated.
The cup filler may alternatively be activated/deactivated using X while all unit instruments rest.
Figure 55 – Foot control of cup filler
AUTOMATIC FUNCTION
The cuspidor flush starts automatically after the cup filler has been activated and when the patient
chair reaches the entry-position.
3.23 ASSISTANT CALL
Activating O while all unit instruments are at rest will activate a relay contact that may be
connected to a bell or other external signaling devices.
X
