You can transfer all data stored in one FT-90R to another FT-90R by utilizing the
handy “Cloning” feature. This requires a user-constructed Cloning cable which
connects the MIC jacks on the two transceivers, as shown below.
To clone from one transceiver to another, use the following procedure:
1. Insert the Clone Cable into the MIC jack of each transceiver.
2. Turn both transceivers off, then press and hold in the microphone’s
[
ACC
]
button (on each radio) while turning the power on again. The “
CLONE
” indica-
tion will appear on the display.
3. On the “destination” radio, press the button. The “
R
” indicator will ap-
pear at the bottom left corner on the display (in the Frequency Control display
mode).
4. Now, on the “source” radio, press the key. The “
T
” indicator will ap-
pear in the bottom left corner on the display, and the cloning data transfer will
immediately begin.
5. If there is a problem during the cloning process, “
Error
” will be displayed.
Check your cable connections, and try again.
6. If cloning was successful, turn the “destination” radio off. Now turn the “source”
radio off.
7. Remove the Clone Cable. Channel and operating data for both radios are now
identical. They both may be turned on now for normal operation.
