8 Displaying the Battery Voltage

Display the battery voltage. When the optional external power supply adapter with a cig-

arette plug (SDD-13) is connected, the power supply voltage of this adapter is displayed.

1. Press and hold the [DISP] key, and then touch [DISPLAY].

2. Rotate the DIAL knob, then touch [8 SENSOR INFO].

3. The battery voltage is shown on the LCD.

• The indication differs depending on the type of the power supply used.

Battery pack: “Lit”

Battery case: “Dry”

External power supply adapter: “Ext”

• During mono band receive, the voltage can be displayed on the LCD constantly.

9 Displaying the Software Version

Display the software version.

1. Press and hold the [DISP] key, and then touch [DISPLAY].

2. Rotate the DIAL knob, then touch [9 SOFTWARE VERSION].

3. The software versions of “Main”, “Sub” and “DSP” are shown.
