68
4 T
urn the VW mode selection ON or OFF
.
Set the digital voice FR (VW) mode selection.
1.
Press and hold the [
DISP
] key
, and then touch [
TX/RX
].
2.
T
ouch [
2 DIGIT
AL
].
3.
T
ouch [
4 DIGIT
AL VW
].
4.
Rotate the
DIAL
knob to select the desired setting.
ON
The digital voice FR (VW) mode may be selected.
OFF
The digital voice FR (VW) mode may not be selected.
Remark
The default setting: OFF
69
71
