69
3 AUDIO
1 Adjusting the Microphone Sensitivity (Microphone Gain)
You can adjust the input level of the built-in microphone or an optional external micro-
phone.
1. Press and hold the [DISP] key, and then touch [TX/RX].
2. Touch [3 AUDIO].
3. Touch [1 MIC GAIN].
4. Rotate the DIAL knob to select the desired microphone sensitivity level.
5. Select a microphone gain level from LEVEL 1 to LEVEL 9.
Remark The default setting: LEVEL 5
• Increasing the microphone gain excessively can distort the sound or pick up the
surrounding noise, impairing intelligibility.
• Be sure to check the microphone gain whenever the microphone is changed.
2 Muting Audio
In the dual receive mode, the audio being received on the non-operating band can be
muted.
1. Press and hold the [DISP] key, and then touch [TX/RX].
2. Touch [3 AUDIO].
3. Touch [2 MUTE].
4. Rotate the DIAL knob to select the desired mute setting.
OFF Disable the muting audio.
MUTE 30% Mute the audio level set to 30%.
MUTE 50% Mute the audio level set to 50%.
MUTE 100% Mute the audio level set to 100%.
3 Simultaneous Radio Broadcast Reception
Set the time to resume radio broadcast reception after transmit/receive when using si-
multaneously receive mode, by selecting [3 AUDIO]→[3 RX AF DUAL].
For additional details, refer to the Advanced Manual which may be downloaded from the
Yaesu website.
4 Setting the VOX (automatic voice transmission) Function
Set the VOX function settings, by selecting [3 AUDIO]→[4 VOX].
For details, see “VOX Operation” on page 47.
5 Setting the Voice Recording Function
Set the Voice Recording function settings, by selecting [3 AUDIO]→[5 RECORDING].
For details, see “Using the Voice Recording” on page 49.
To Next Page
