VALVES AND VALVE SPRINGS
5-19
EAS24270
VALVES AND VALVE SPRINGS
Removing the valves and valve springs
Order Job/Parts to remove Q’ty Remarks
Cylinder head Refer to "CYLINDER HEAD" on page 5-16.
1 Intake valve lifter 8
2 Intake valve pad 8
3 Intake valve cotter 16
4 Intake valve upper spring seat 8
5 Intake valve spring outer 8
6 Intake valve spring inner 8
7 Intake valve stem seal 8
8 Intake valve lower spring seat 8
9 Intake valve 8
10 Intake valve guide 8
11 Exhaust valve lifter 8
12 Exhaust valve pad 8
13 Exhaust valve cotter 16
14 Exhaust valve upper spring seat 8
15 Exhaust valve spring 8
16 Exhaust valve stem seal 8
17 Exhaust valve lower spring seat 8
18 Exhaust valve 8
19 Exhaust valve guide 8
To Next Page
