CHASSIS SPECIFICATIONS
2-9
EAS20300
CHASSIS SPECIFICATIONS
Chassis
Frame type Diamond
Caster angle 25.00 °
Trail 97.5 mm (3.84 in)
Front wheel
Wheel type Cast wheel
Rim size 17M/C x MT3.50
Rim material Aluminum
Wheel travel 130.0 mm (5.12 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Rear wheel
Wheel type Cast wheel
Rim size 17M/C x MT5.50
Rim material Aluminum
Wheel travel 130.0 mm (5.12 in)
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Front tire
Type Tubeless
Size 120/70 ZR17M/C (58W)
Manufacturer/model BRIDGESTONE/BT020F GG
Manufacturer/model DUNLOP/D252F
Wear limit (front) 0.8 mm (0.03 in)
Rear tire
Type Tubeless
Size 180/55 ZR17M/C (73W)
Manufacturer/model BRIDGESTONE/BT020R GG
Manufacturer/model DUNLOP/D252
Wear limit (rear) 0.8 mm (0.03 in)
Tire air pressure (measured on cold tires)
Loading condition 0–90 kg (0–198 lb)
Front 225 kPa (33 psi) (2.25 kgf/cm²) (2.25 bar)
Rear 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Loading condition 90–185 kg (198–408 lb) (FZ6-SA/FZ6-SAHG)
90–190 kg (198–419 lb) (FZ6-S/FZ6-SHG(W))
90–191 kg (198–421 lb) (FZ6-NA/FZ6-NAHG)
90–196 kg (198–432 lb) (FZ6-N/FZ6-NHG(W))
Front 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Rear 290 kPa (42 psi) (2.90 kgf/cm²) (2.90 bar)
High-speed riding
Front 225 kPa (33 psi) (2.25 kgf/cm²) (2.25 bar)
Rear 250 kPa (36 psi) (2.50 kgf/cm²) (2.50 bar)
Front brake
Type Dual disc brake
Operation Right hand operation
Front disc brake
Disc outside diameter × thickness 298.0 × 5.0 mm (11.73 × 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc deflection limit 0.10 mm (0.0039 in)
Brake pad lining thickness (inner) 4.5 mm (0.18 in) (FZ6-SHG(W)/FZ6-SAHG/
FZ6-NHG(W)/FZ6-NAHG)
