SIGNALING SYSTEM
8-21
EAS27290
TROUBLESHOOTING
• Any of the following fail to light: turn signal light, brake light or an indicator light.
• The horn fails to sound.
NOTE:
• Before troubleshooting, remove the following part(s):
1.Seat
2.Front cowling inner panel
3.Fuel tank
4.Side cover
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
Check the signaling system
The horn fails to sound.
NG→
OK↓
NG→
OK↓
1. Check the fuses.
(Main, ignition, signaling and tail)
Refer to "CHECKING THE
FUSES" on page 8-113.
Replace the fuse(s).
2. Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-114.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the main switch.
Refer to "CHECKING THE
SWITCHES" on page 8-109.
Replace the main switch.
4. Check the entire signaling sys-
tem’s wiring.
Refer to "CIRCUIT DIAGRAM" on
page 8-1.
Properly connect or repair the signal-
ing system’s wiring.
This circuit is OK.
1. Check the horn switch.
Refer to "CHECKING THE
SWITCHES" on page 8-109.
Replace the left handlebar switch.
2. Check the horn.
Refer to "CHECKING THE
HORN" on page 8-125.
Replace the horn.
To Next Page
