ELECTRICAL SPECIFICATIONS
2-12
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system Transistorized coil ignition (digital)
Ignition system type DC. TCI
Advancer type Digital
Ignition timing (B.T.D.C.) 5.0 °/1300 r/min
Engine control unit
Model/manufacturer FUA0015/MITSUBISHI (FZ6-SHG(W)/FZ6-
NHG(W))
FUA0018/MITSUBISHI (FZ6-NAHG/FZ6-
SAHG)
FUA0019/MITSUBISHI (FZ6-SA/FZ6-NA)
FUA0020/MITSUBISHI (FZ6-S/FZ6-N)
Ignition coil
Model/manufacturer JO383/DENSO
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.53–2.07 Ω at 20°C (68°F)
Secondary coil resistance 12.0–18.0 kΩ at 20°C (68°F)
Spark plug cap
Material Resin
Resistance 10.0 kΩ
AC magneto
Model/manufacturer F5VX/MORIC
Stator coil resistance 0.22–0.34 Ω at 20°C (68°F)
Standard output 14.0 V310 W5000 r/min
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer SH719AA/SHINDENGEN
No load regulated voltage 14.1–14.9 V
Rectifier capacity 25.0 A
Withstand voltage 240.0 V
Battery
Model GT12B-4
Voltage, capacity 12 V, 10.0 Ah
Specific gravity 1.320
Manufacturer GYM
Ten hour rate amperage 1.00 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 60 W/55.0 W × 1 (FZ6-N/FZ6-NA/FZ6-
NHG(W)/FZ6-NAHG)
12 V, 55.0 W × 1 (FZ6-S/FZ6-SA/FZ6-
SHG(W)/FZ6-SAHG)
Auxiliary light 12 V, 5.0 W × 1 (FZ6-N/FZ6-NA/FZ6-NHG(W)/
FZ6-NAHG)
