ELECTRICAL SPECIFICATIONS
2-13
12 V, 5.0 W × 2 (FZ6-S/FZ6-SA/FZ6-SHG(W)/
FZ6-SAHG)
Tail/brake light 12 V, 5.0 W/21.0 W × 1
Front turn signal light 12 V, 10.0 W × 2
Rear turn signal light 12 V, 10.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED (FZ6-SHG(W)/FZ6-SAHG/FZ6-NHG(W)/
FZ6-NAHG)
EL backlight LCD (FZ6-S/FZ6-SA/FZ6-N/FZ6-
NA)
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
High beam indicator light LED
Coolant temperature warning light LED (FZ6-SHG(W)/FZ6-SAHG/FZ6-NHG(W)/
FZ6-NAHG)
Engine trouble warning light LED
Immobilizer system indicator light LED
ABS warning light LED (FZ6-NA/FZ6-NAHG/FZ6-SA/FZ6-SAHG)
Electric starting system
System type Constant mesh
Starter motor
Model/manufacturer SM-14/MITSUBA
Power output 0.60 kW
Armature coil resistance 0.0012–0.0022 Ω
Brush overall length 10.0 mm (0.39 in)
Limit 3.50 mm (0.14 in)
Brush spring force 7.16–9.52 N (25.77–34.27 oz) (730–971 gf)
Commutator diameter 28.0 mm (1.10 in)
Limit 27.0 mm (1.06 in)
Mica undercut (depth) 0.70 mm (0.03 in)
Starter relay
Model/manufacturer MS5F-441/JIDECO
Amperage 180.0 A
Coil resistance 4.18–4.62 Ω at 20°C (68°F)
Horn
Horn type Plane
Quantity 1 pcs
Model/manufacturer HF-12/NIKKO
Maximum amperage 3.0 A
Coil resistance 1.01–1.11 Ω
Performance 105–118 dB/2m
Turn signal relay
Relay type Full transistor
Model/manufacturer FE218BH/DENSO
Built-in, self-canceling device No
Turn signal blinking frequency 75.0–95.0 cycles/min
Wattage 10 W × 2 + 3.4 W
Oil level switch
Model/manufacturer 5VX/SOMIC ISHIKAWA
