TIGHTENING TORQUES
2-21
Seat lock and frame M6 2 7 Nm (0.7 m·kg, 5.0 ft·lb)
Licence plate light screw M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Rear reflector bolt M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Flap and bracket 6 M6 2 7 Nm (0.7 m·kg, 5.0 ft·lb)
Bracket 6 and rear frame M6 2 19 Nm (1.9 m·kg, 14 ft·lb)
Tail/brake right unit screw M6 2 3 Nm (0.3 m·kg, 2.2 ft·lb)
Rear fender cover bolt M5 4 4 Nm (0.4 m·kg, 2.9 ft·lb)
Seat handle bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)
Muffler and rear fender bolt M6 4 7 Nm (0.7 m·kg, 5.0 ft·lb)
Side cover bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Lean angle sensor bolt M4 2 2 Nm (0.2 m·kg, 1.4 ft·lb)
Coolant reservoir tank cover bolt M6 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Front wheel axle shaft bolt M18 1 72 Nm (7.2 m·kg, 52 ft·lb)
Front brake caliper bolt M10 4 40 Nm (4.0 m·kg, 29 ft·lb)
Front brake disc bolt M6 10 18 Nm (1.8 m·kg, 13 ft·lb)
Brake caliper bleed screw M7 3 6 Nm (0.6 m·kg, 4.3 ft·lb)
Rear wheel axle nut M24 1 120 Nm (12 m·kg, 87 ft·lb)
Rear brake disc and rear wheel M8 5 30 Nm (3.0 m·kg, 22 ft·lb)
Rear brake caliper bolt front and
rear brake caliper bracket
M8 1 27 Nm (2.7 m·kg, 20 ft·lb)
Rear brake caliper bolt rear and
rear brake caliper bracket
M8 1 22 Nm (2.2 m·kg, 16 ft·lb)
Rear wheel sprocket and rear
wheel drive hub
M10 6 100 Nm (10 m·kg, 72 ft·lb)
Chain adjusting bolt lock nut M8 2 16 Nm (1.6 m·kg, 12 ft·lb)
Rear brake hose union bolt M10 1 30 Nm (3.0 m·kg, 22 ft·lb)
Sidestand bolt M10 1 46 Nm (4.6 m·kg, 33 ft·lb)
Sidestand bracket and frame M10 2 63 Nm (6.3 m·kg, 46 ft·lb)
Sidestand switch screw M5 2 4 Nm (0.4 m·kg, 2.9 ft·lb)
Footrest bracket and frame M8 4 30 Nm (3.0 m·kg, 22 ft·lb)
Rear brake reservoir tank and
bracket
M6 1 3 Nm (0.3 m·kg, 2.2 ft·lb)
Rear master cylinder and footrest
bracket
M8 2 23 Nm (2.3 m·kg, 17 ft·lb)
Centerstand bolt M10 2 73 Nm (7.3 m·kg, 53 ft·lb)
Front wheel sensor bolt (with
ABS)
M6 1 7 Nm (0.7 m·kg, 5.0 ft·lb)
Rear wheel sensor bolt (with
ABS)
M6 1 7 Nm (0.7 m·kg, 5.0 ft·lb)
ECU bolt (engine control unit) M6 2 7 Nm (0.7 m·kg, 5.0 ft·lb)
Bracket and hydraulic unit bracket
1 bolt (with ABS)
M6 6 10 Nm (1.0 m·kg, 7.2 ft·lb)
Hydraulic unit bracket 1 and
hydraulic unit bracket 2 bolt (with
ABS)
M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
