Components
33
EMU38591
Remote control transmitter (if
equipped)
The lock and unlock modes of the Yamaha
Security System are selected using the re-
mote control transmitter. While the engine is
running, input from the remote control trans-
mitter is not received.
Store the remote control transmitter carefully
so it will not be lost.
NOTICE
ECM02100
● The remote control transmitter is not
completely waterproof. Do not sub-
merge the transmitter or operate it un-
derwater. If the transmitter is
submerged, dry it with a soft, dry cloth,
1
4
6
3
2
5
ZMU05429
1. Tachometer unit (Square type)*
2. Tachometer unit (Round type)*
3. Speedometer unit (Square type)*
4. Speed & fuel meter unit (Square type)*
5. Speed & fuel meter unit (Round type)*
6. Fuel management meter (Square type)*
ZMU06455
