Instruments and indicators
52
EMU36190
Start-up checks
Place the remote control lever / gear shift le-
ver in neutral and turn the main switch to “”
(on). After all the displays come on and the to-
tal hour display comes on, the gauge will
change to normal operation. If the buzzer
sounds and the water separator-alert indica-
tor blinks, consult your Yamaha dealer imme-
diately.
T
IP:
To stop the buzzer, press the “” (set) or
“” (mode) button.
EMU38621
Yamaha Security System information
(if equipped)
Turn the main switch to the “” (on) position,
the currently selected Yamaha Security Sys-
tem mode (Lock / Unlock) will show on the
display.
Unlock mode
Lock mode
1. Set button
2. Mode button
1. Tachometer
2. Trim meter
3. Multifunction display
4. Water detection-alert indicator
5. Engine trouble alert/maintenance indicator
6. Cooling water pressure
7. Oil pressure (4-stroke models)
8. Cooling water/engine temperature
9. Battery voltage
2
1
ZMU05417
1452
3
6879
ZMU05418
ZMU06457
ZMU06458
ZMU06459
U63P1DE0.book Page 52 Tuesday, March 29, 2011 7:15 PM
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F115 Specifications

General

Displacement	1832cc
Prop Shaft Horsepower	115 hp
Alternator Output	35 Amp
Gear Ratio	2.15:1
Starting System	Electric
Fuel Recommendation	Regular Unleaded (Minimum Pump Octane 87)
Oil Recommendation	Yamalube 4M
Exhaust	Through Propeller
Lubrication	Wet Sump
Steering	Remote
Cooling System	Water Cooled
Bore x Stroke	81.0 x 88.9 mm
Full Throttle RPM Range	5300-6300 rpm
Fuel Induction System	EFI (Electronic Fuel Injection)
Ignition System	TCI (Transistor Controlled Ignition)
Weight	377 lbs
Cooling	Water Cooled
Shaft Length	L = 20 inch, X = 25 inch
