Yamaha F115 User Manual

Operation
82
EMU42700
Procedure for tilting down (power trim
and tilt models)
1. Push the power trim and tilt switch “”
(up) until the outboard motor is supported
by the tilt rod and the tilt support lever be-
comes free.
2. Release the tilt support lever.
3. Push the power trim and tilt switch “”
(down) to lower the outboard motor to the
desired position.
EMU28062
Shallow water
EMU32851
Power trim and tilt models
The outboard motor can be tilted up partially
to allow operation in shallow water.
NOTICE
ECM00260
Do not tilt the outboard motor up so that
the cooling water inlet on the lower unit is
above the surface of the water when set-
ting up for and cruising in shallow water.
Otherwise severe damage from overheat-
ing can result.
EMU32913
Procedure for power trim and tilt models
1. Place the remote control lever / gear shift
lever in neutral.
DN
ZMU01936
UP
DN
ZMU04603
DN
DN
ZMU04255
U63P1DE0.book Page 82 Tuesday, March 29, 2011 7:15 PM
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F115 Specifications

General

Displacement	1832cc
Prop Shaft Horsepower	115 hp
Alternator Output	35 Amp
Gear Ratio	2.15:1
Starting System	Electric
Fuel Recommendation	Regular Unleaded (Minimum Pump Octane 87)
Oil Recommendation	Yamalube 4M
Exhaust	Through Propeller
Lubrication	Wet Sump
Steering	Remote
Cooling System	Water Cooled
Bore x Stroke	81.0 x 88.9 mm
Full Throttle RPM Range	5300-6300 rpm
Fuel Induction System	EFI (Electronic Fuel Injection)
Ignition System	TCI (Transistor Controlled Ignition)
Weight	377 lbs
Cooling	Water Cooled
Shaft Length	L = 20 inch, X = 25 inch
