Components
35
EMU26181
Remote control box
The remote control lever actuates both the
shifter and the throttle. The electrical switches
are mounted on the remote control box.
EMU26190
Remote control lever
Moving the lever forward from the neutral po-
sition engages forward gear. Pulling the lever
back from neutral engages reverse. The en-
gine will continue to run at idle until the lever
is moved about 35° (a detent can be felt).
Moving the lever farther opens the throttle,
and the engine will begin to accelerate.
Yamaha
Security
System
mode
Number
of beeps
Main
switch
Engine
can be
started
Lock 1 beep
“”
NO
Unlock 2 beeps
“”/
“”
YES
1. Power trim and tilt switch
2. Remote control lever
3. Neutral interlock trigger
4. Neutral throttle lever
5. Main switch
6. Engine shut-off switch
7. Throttle friction adjuster
1. Remote control lever
2. Power trim and tilt switch
3. Free accelerator
4. Throttle friction adjuster
2
3
2
1
4
ZMU04569
1. Neutral “”
2. Forward “”
3. Reverse “”
4. Shift
5. Fully closed
6. Throttle
7. Fully open
1. Neutral “”
2. Forward “”
3. Reverse “”
4. Shift
5. Fully closed
6. Throttle
7. Fully open
N
1
F
7
6
2
R
3
4
4
6
5
7
5
ZMU04573
