APPENDIX ➤ Specifications En 138
Input jacks
• Analog Audio
[RX-V777]
[U.S.A. and Canada models]
Audio x 4 (AV 5–6, AUDIO 1–2)
[Other models]
Audio x 5 (AV 5–6, AUDIO 1–2, PHONO)
[RX-V677]
Audio x 4 (AV 5–6, AUDIO 1–2)
• Digital Audio (Supported frequencies: 32 kHz to 96 kHz)
Optical x 2 (AV 1, AV 4)
Coaxial x 2 (AV 2–3)
•Video
Composite x 5 (AV 3–6, VIDEO [Front Panel])
Component x 2 (AV 1–2)
• HDMI Input
HDMI x 6 (HDMI 1–5, V-AUX*)
* V-AUX: MHL input compatible
•Other
USB x 1 (USB2.0)
NETWORK x 1 (100Base-TX/10Base-T)
Output jacks
• Analog Audio
[RX-V777]
- Speaker Out x 9 (7 ch)
(FRONT L/R, CENTER,
SURROUND L/R, SURROUND BACK L/R
*1
, EXTRA SP L/R
*2
)
*1 Note: Assignment is possible [SURROUND BACK,
BI-AMP (FRONT L/R)]
*2 Note: Assignment is possible [ZONE2, PRESENCE]
- Pre Out x 7 (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R)
- Subwoofer Out x 2 (SUBWOOFER 1–2, mono)
- AV OUT x 1
- ZONE2 OUT x 1
- Headphone x 1
[RX-V677]
- Speaker Out x 9 (7 ch)
(FRONT L/R, CENTER,
SURROUND L/R, SURROUND BACK L/R
*1
, EXTRA SP L/R
*2
)
*1 Note: Assignment is possible [SURROUND BACK,
BI-AMP (FRONT L/R)]
*2 Note: Assignment is possible [ZONE2, PRESENCE]
- Subwoofer Out x 2 (SUBWOOFER 1–2, mono)
- AV OUT x 1
- ZONE2 OUT x 1
- Headphone x 1
•Video
MONITOR OUT
- Component x 1
- Composite x 1
AV OUT
- Composite x 1
• HDMI Output
[RX-V777]
HDMI OUT x 2 (HDMI OUT 1–2)
[RX-V677]
HDMI OUT x 1
Other jacks
• YPAO MIC x 1
• REMOTE IN x 1
• REMOTE OUT x 1
• TRIGGER OUT x 1
• DC OUT x 1
HDMI
• HDMI features: Deep Color, “x.v.Color,” Auto Lip Sync, ARC
(Audio Return Channel), 3D, 4K Ultra HD
• Video Format (Repeater Mode)
-VGA
- 480i/60 Hz
- 576i/50 Hz
- 480p/60 Hz
- 576p/50 Hz
- 720p/60 Hz, 50 Hz
- 1080i/60 Hz, 50 Hz
- 1080p/60 Hz, 50 Hz, 30 Hz, 25 Hz, 24 Hz
- 4K/60 Hz, 50Hz, 30 Hz, 25 Hz, 24 Hz
• Audio Format
-Dolby TrueHD
- Dolby Digital Plus
- Dolby Digital
- DTS-HD Master Audio
- DTS-HD High Resolution Audio
- DTS Express
-DTS
- DSD 2-ch to 6-ch
- PCM 2-ch to 8-ch (Max. 192 kHz/24-bit)
• Content Protection: HDCP compatible
• Link Function: CEC supported
Specifications

Yamaha RX-V677 Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Dynamic power per channel (4 Ohm)	190 W
Dynamic power per channel (8 Ohm)	125 W
Power output per channel (1KHz@8 Ohm)	105 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN, RUS
Power consumption (standby)	0.15 W

Weight and Dimensions

Depth	365 mm
Width	435 mm
Height	171 mm
Weight	10025 g
