Yamaha RX-V677 User Manual

CONFIGURATIONS ➤ Configuring various functions (Setup menu) En 98
Setup menu items
Menu Item Function Page
Speaker
Auto Setup Automatically optimizes the speaker settings (YPAO). 34
Manual Setup
Power Amp Assign Selects a speaker system. 100
Configuration
Front Selects the size of the front speakers. 100
Center Selects whether or not a center speaker is connected and its size. 100
Surround Selects whether or not surround speakers are connected and their size. 100
Surround Back Selects whether or not surround back speakers are connected and their size. 101
Front Presence Selects whether or not presence speakers are connected. 101
Subwoofer Selects whether or not a subwoofer is connected and its phase. 101
Layout Selects a surround speaker layout when surround speakers are used. 101
Bass Cross Over Sets the lower limit of the low-frequency component that can be output from speakers whose size is set to “Small”. 101
Distance Sets the distance between each speaker and listening position. 102
Level Adjusts the volume of each speaker. 102
Parametric EQ Adjusts the tone with an equalizer. 102
Test Tone Enables/disables the test tone output. 103
Sound
Lipsync
Delay Enable Enables/disables the Lipsync adjustment for each input source. 103
Auto/Manual Select Selects the method to adjust the delay between video and audio output. 103
Adjustment Adjusts the delay between video and audio output manually. 104
Dynamic Range Selects the dynamic range adjustment method for bitstream audio (Dolby Digital and DTS signals) playback. 104
Max Volume Sets the maximum volume to prevent excessive loudness. 104
Initial Volume Sets the initial volume for when this receiver is turned on. 104
Adaptive DSP Level Selects whether to automatically adjust the CINEMA DSP effect level when the volume is adjusted. 104
CINEMA DSP 3D Mode Enables/disables CINEMA DSP 3D. 104
Extended Surround Selects how to play back 5.1- to 7.1-channel sources when surround back speakers are used. 104
Video Video Mode Enables/disables the video signal processing (resolution and aspect ratio). 105
HDMI
HDMI Control Enables/disables HDMI Control. You can also configure the relevant settings (such as ARC and TV audio input). 106
Audio Output Selects a device to output audio. 107
Standby Through Select whether to output videos/audio (input through HDMI jacks) to the TV when the unit is in standby mode. 107

Yamaha RX-V677 Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Dynamic power per channel (4 Ohm)	190 W
Dynamic power per channel (8 Ohm)	125 W
Power output per channel (1KHz@8 Ohm)	105 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	6
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIx, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN, RUS
Power consumption (standby)	0.15 W

Weight and Dimensions

Depth	365 mm
Width	435 mm
Height	171 mm
Weight	10025 g
