Intake manifold
17 Clamp 1
18 Oil level pipe plate 1
19 Grommet 1
20 O-ring 1 Not reusable
No. Part name
Q
’ty
Remarks
A
1
6
5
5
10
9
2
8
7
11
4
3
14
13
12
15 17
18
19
20
16
6
LT
242
LT
572
LT
572
1322D
1322D
15 Nm (1.5 kgf
·
m, 11.1 ft
·
Ib)
16 Nm (1.6 kgf·m, 11.8 ft·Ib)
31 Nm (3.1 kgf·m, 22.9 ft·Ib)
1
2
16 Nm (1.6 kgf·m, 11.8 ft·Ib)
31 Nm (3.1 kgf·m, 22.9 ft·Ib)
1
2
10 Nm (1.0 kgf·m, 7.4 ft·lb)
20 Nm (2.0 kgf·m, 14.8 ft·lb)
1
2
19 Nm (1.9 kgf
·
m, 14.0 ft
·
Ib)
4
