Oil cooler, oil pump, and drive gear
5-28
17 O-ring 4 Not reusable
18 Connector 2
19 Bolt 7
M6
× 25 mm
20 Washer 3
21 Bolt 1
M8
× 25 mm
22 Bolt 4
M6
× 20 mm
23 Gasket 1 Not reusable
24 Dowel 2
25 Oil filter joint 1
No. Part name
Q
’ty
Remarks
E
A
A
A
LT
572
LT
572
LT
572
LT
572
LT
572
LT
572
6
5
4
8
7
7
6
22
17
18
17
17
18
17
22
24
24
13
11
12
23
21
15
20
19
15
19
14
16
3
2
1
19
10
9
9
25
11 Nm (1.1 kgf
·
m, 8.1 ft
·
Ib)
80 Nm (8.0 kgf
·
m, 59.0 ft
·
Ib)
19 Nm (1.9 kgf
·
m, 14.0 ft
·
Ib)
19 Nm (1.9 kgf
·
m, 14.0 ft
·
Ib)
12 Nm (1.2 kgf
·
m, 8.9 ft
·
Ib)
12 Nm (1.2 kgf
·
m, 8.9 ft
·
Ib)
20 Nm (2.0 kgf
·
m, 14.8 ft
·
Ib)
18 Nm (1.8 kgf
·
m, 13.3 ft
·
Ib)
