A.2 Single/Three-Phase 200 V Class Drive
Table A.2 Power Ratings
Item Specification
Three-Phase Drive Model
2A0001 2A0002 2A0004 2A0006 2A0008 2A0010 2A0012 2A0018 2A0020
Single-Phase Drive Model
<1>
BA0001 BA0002 BA0003 BA0006 - BA0010 - - -
Maximum Motor Size
Allowed (kW)
<2>
ND
Rating
0.2 0.4 0.75 1.1 1.5 2.2 3.0 3.7 5.5
HD
Rating
0.1 0.2 0.4 0.75 1.1 1.5 2.2 3.0 3.7
Input
Input
Current
(A)
<3>
Three-
Phase
ND
Rating
1.1 1.9 3.9 7.3 8.8 10.8 13.9 18.5 24.0
HD
Rating
0.7 1.5 2.9 5.8 7.0 7.5 11.0 15.6 18.9
Single-
Phase
ND
Rating
2.0 3.6 7.3 13.8 – 20.2 – – –
HD
Rating
1.4 2.8 5.5 11.0 – 14.1 – – –
Output
Rated Output
Capacity (kVA)
<4>
ND
Rating
0.5 0.7 1.3 2.3 3.0 3.7 4.6 6.7 7.5
HD
Rating
0.3 0.6 1.1 1.9 2.6 3.0 4.2 5.3 6.7
Output Current
(A)
ND
Rating
<5>
1.2 1.9
3.5
(3.3)
6.0 8.0 9.6 12.0 17.5 19.6
HD
Rating
0.8
<6>
1.6
<6>
3.0
<6>
5.0
<6>
6.9
<7>
8.0
<7>
11.0
<7>
14.0
<7>
17.5
<7>
Overload Tolerance
ND Rating: 120% of rated output current for 1 minute
HD Rating: 150% of rated output current for 1 minute
(Derating may be required for applications that start and stop frequently)
Carrier Frequency 2 kHz (user-set, 2 to 15 kHz)
Max Output Voltage (V)
Three-phase power: 200 to 240 V
Single-phase power: 200 to 240 V
(both proportional to input voltage)
Max Output Frequency
(Hz)
400 Hz (user-adjustable)
Power
Supply
Rated Voltage
Rated Frequency
Three-phase power: 200 to 240 V 50/60 Hz
Single-phase power: 200 to 240 V 50/60 Hz
DC power supply: 270 to 340 V
<8>
Allowable Voltage
Fluctuation
-15 to 10%
Allowable Frequency
Fluctuation
±5%
A.2 Single/Three-Phase 200 V Class Drive
