Table B.4 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD settings
No. Description Unit Default Settings
− Model − 2A0001 2A0002 2A0004 2A0006 2A0008
o2-04 Drive Model Selection − 96 (60H) 97 (61H) 98 (62H) 99 (63H) 100 (64H)
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1 0 1
− Motor rated power kW 0.1 0.18 0.25 0.37 0.55 0.75 1.1 1.1 1.1 1.5
C6-02 Carrier frequency − 4 7 4 7 4 7 4 7 3 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30 3.30 4.90 4.90 6.20
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50 2.50 2.60 2.60 2.60
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80 1.80 2.30 2.30 2.80
E2-05
Motor line-to-line
resistance
Ω
35.9
8
20.5
6
20.5
6
9.84
9.84
2
5.15
6
5.15
6
3.57
7
3.57
7
1.99
7
−
Momentary power loss
ride-through time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
−
Momentary power loss
Baseblock time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.4
No. Description Unit Default Settings
− Model − 2A0010 2A0012 2A0018 2A0020
o2-04 Drive Model Selection − 101 (65H) 102 (66H) 103 (67H) 104 (68H)
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
− Motor rated power kW 1.5 2.2 2.2 3.0 3.0 3.7 4.0 5.5
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01 Motor rated current A 6.20 8.50 8.50 11.40 11.40 14.00 14.00 19.60
E2-02 Motor rated slip Hz 2.60 2.90 2.90 2.70 2.70 2.73 2.73 1.50
E2-03 Motor no-load current A 2.80 3.00 3.00 3.70 3.70 4.50 4.50 5.10
E2-05
Motor line-to-line
resistance
Ω 1.997 1.601 1.601 1.034 1.034 0.771 0.771 0.399
−
Momentary power loss
ride-through time
s 0.3 0.3 0.5 0.5 1 1 1 1
−
Momentary power loss
Baseblock time
s 0.4 0.5 0.5 0.5 0.5 0.6 0.6 0.7
B.4 Defaults by Drive Model and Duty Rating ND/HD
