Yealink CTP18 Administrator's Guide

| Getting Started | 17
Port Name Description
7 Security Slot Allow you to connect a universal security cable to the VCS endpoint,
so you can lock the VCS endpoint down. The VCS endpoint cannot be
removed when locked.
Hardware of VC880 Codec
With rich physical interfaces for audio and video connection, VC880 can be connected to the 3rd-party
camera or access to the video matrix. Possessing rich physical interfaces for audio and video connection,
the system can be connected to the 3rd-party camera or access to the video matrix. In addition, it comes
with the professional RCA-in/out interface that integrates the mixer with the gooseneck microphone. Its
spilt-type structure can meet the deployment requirement of the control room which separates from a large
conference room.
The following introduces the corresponding ports on VC880.
Port Name Description
1 LED Indicator Indicate different status of the system.
2 Reset Key
Reset the VCS endpoint to factory defaults.
3 USB
• Insert a USB flash drive.
USB flash drive can be used for storing screenshots, recorded
videos or captured packets. If you insert multiple USB flash drives to
the VCS endpoint simultaneously, only the last USB flash drives you
insert can be identified by the endpoint.
• Insert a WF50 Wi-Fi USB Dongle for connecting to Wi-Fi or
providing wireless AP.
• Insert a BT42 Bluetooth USB Dongle for connecting to the CPW90-
BT Bluetooth wireless microphones.
• Insert a PSTN box CPN10 for connecting to the PSTN (Public
Switched Telephone Network).
4 Camera Port Connect to a third-party camera.

Yealink CTP18 Specifications

General

Aspect ratio	16:10
Display diagonal	8 \
Display resolution	1280 x 800 pixels
Touchscreen technology	Capacitive
Built-in speaker(s)	No
Ethernet LAN	Yes
Mounting type	Wall/Tabletop
Product color	Black, Grey
RJ-45 ports quantity	1
Cables included	LAN (RJ-45)
Power source type	DC
Power consumption (typical)	7 W

Weight and Dimensions

Depth	100 mm
Width	202 mm
Height	151 mm
