Yealink CTP18 Administrator's Guide

| Getting Started | 40
Rear Panel of MSpeaker
Name Description
1 Power Input It is used to connect MSpeaker to the power adapter.
2 AUX In It is used to connect MSpeaker to VC800 Line Out Port
as an audio input.
Hardware of MSpeaker II
Front Panel of MSpeaker II
Rear Panel of MSpeaker II
Name Description
1 Power Input It is used to connect MSpeaker to the power adapter.
2 Line In It is used to connect MSpeaker II to the Line Out Port as
an audio input.
3 Audio It is used to connect MSpeaker to the VC Hub/Camera
Port as an audio input.

Yealink CTP18 Specifications

General

Aspect ratio	16:10
Display diagonal	8 \
Display resolution	1280 x 800 pixels
Touchscreen technology	Capacitive
Built-in speaker(s)	No
Ethernet LAN	Yes
Mounting type	Wall/Tabletop
Product color	Black, Grey
RJ-45 ports quantity	1
Cables included	LAN (RJ-45)
Power source type	DC
Power consumption (typical)	7 W

Weight and Dimensions

Depth	100 mm
Width	202 mm
Height	151 mm
