Yealink CTP18 Administrator's Guide

| Managing the Directory | 224
5. If you import a CSV format contact list, configure and save the following settings:
Parameter Description Configuration Method
The first line as the title
It will prevent importing the title
of the local contact information
which is located in the first line
of the CSV file.
• Check—do not import the
first line of the CSV file.
• Uncheck—import the first line
of the CSV file.
Web user interface
Delete Old Contacts
It will delete all existing local
contacts while importing the
contact list.
• Check—delete the old
contacts.
• Uncheck—do not delete the
old contacts.
Web user interface
Ignore This column will not be imported
to the system.
Web user interface
Display name
This column will be imported to
the system as the local contact’s
name.
Note: This column must be
imported to the system, or you
cannot import the local contact
list.
Web user interface
Group This column will be imported to
the system as the group.
Web user interface
Number This column will be imported to
the system as the local contact’s
number.
Web user interface
Bandwidth This column will be imported to
the system as the local contact’s
bandwidth.
Web user interface
Exporting Local Contact List
You can export a local contact list in XML format from your system. Therefore, you can share it with other
systems.
Procedure
1. On your web user interface, go to Directory > Local Directory.
2. Click Export > XML/CSV.

Yealink CTP18 Specifications

General

Aspect ratio	16:10
Display diagonal	8 \
Display resolution	1280 x 800 pixels
Touchscreen technology	Capacitive
Built-in speaker(s)	No
Ethernet LAN	Yes
Mounting type	Wall/Tabletop
Product color	Black, Grey
RJ-45 ports quantity	1
Cables included	LAN (RJ-45)
Power source type	DC
Power consumption (typical)	7 W

Weight and Dimensions

Depth	100 mm
Width	202 mm
Height	151 mm
