User screen
Figure 53: User screen
This screen allows definition of custom User ID’s and matching passwords. This allows the building
administrator to assign custom passwords to those who are authorized to maintain the chiller.
Each custom user value is not linked to a specific button. Instead, the Change User Attributes
button is pressed which enables the cursor arrows which are used to highlight the custom user
parameter the user wishes to modify. At this point the Enter button is pressed and the value may
be entered.
Table 150: Display only
Field/LED
name
Access level Description
None –
Table 151: Programmable
Field/LED
name
Access level Description
Data display
mode
Operator Define the unit system (English or Metric) used by the chiller display.
Data format Operator
This setpoint allows the date format to be displayed in DDD MMM
YYY (default), DD.MM.YYY or YYYY-MM-DD.
User ID (1-4) Service
This allows the user to specify up to four (4) custom User ID values.
Each User ID will then require a corresponding password and user
level. A User ID can be defined for various maintenance personnel.
155YK-EP Style B Centrifugal Chiller
