History details screen
Figure 60: History details screen
This screen allows the user to see an on-screen printout of all the system parameters at the time of
the selected shutdown. Not all screens are shown above. The number of screens required to display
all of the data varies according to type of motor starter and options applied.
Table 170: Display only
Field/LED name Description
History Printout This is the on-screen printout of the system parameters.
Table 171: Programmable
Button Access level Description
Page Up View Scroll up in the displayed data (if applicable).
Page Down View Scroll down in the displayed data (if applicable).
Print History View
This generates a report listing the status of the chiller parameters at
the time of the selected shutdown.
Table 172: Navigation
Button Access level Description
Home View Returns user to HOME Screen.
History View Returns user to HISTORY Screen.
YK-EP Style B Centrifugal Chiller168
