Intelligent Document Capture 13 - 5
Image Document Capture Parameter Defaults
Table 13-1 lists defaults for IDC parameters. Change these values in one of two ways:
Scan the appropriate bar codes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 9-5.
Configure the scanner using the 123Scan
configuration program. See Chapter 16, 123Scan and Software
Tools.
Alternatively, use the sample application to set parameters using the parameter name. The application provides
prompts and error checking to assist in setting the parameters correctly and easily. You must use an application to
set a parameter to a negative value, as the IDC X Coordinate can require.
NOTE See Appendix A, Standard Parameter Defaults for all user preference, host, symbology, and
miscellaneous default parameters.
Table 13-1 Intelligent Document Capture (IDC) Parameter Defaults
Parameter Parameter Name
Parameter
Number
1
SSI
Number
2
Default
Page
Number
Intelligent Document Capture (IDC) Parameters
IDC Operating Mode DocCap_MODE 594 F1h 52h Off
13-7
IDC Symbology DocCap_SYMBOLOGY 655 F1h 8Fh 001
13-8
IDC X Coordinate DocCap_X 596 F4h F1h 54h -151
13-9
IDC Y Coordinate DocCap_Y 597 F4h F1h 55h -050
13-9
IDC Width DocCap_WIDTH 598 F1h 56h 0300
13-10
IDC Height DocCap_HEIGHT 599 F1h 57h 0050
13-10
IDC Aspect DocCap_ASPECT 595 F1h 53h 000
13-11
IDC File Format Selector DocCap_FMT 601 F1h 59h JPEG
13-11
IDC Bits Per Pixel DocCap_BPP 602 F1h 5Ah 8 BPP
13-12
IDC JPEG Quality DocCap_JPEG_Qual 603 F1h 5Bh 065
13-12
IDC Find Box Outline Sig_FINDBOX 727 F1h D7h Disable
13-13
IDC Minimum Text Length DocCap_MIN_TEXT 656 F1h 90h 00
13-13
IDC Maximum Text Length DocCap_MAX_TEXT 657 F1h 91h 00
13-14
IDC Captured Image Brighten Sig_BRIGHTEN 654 F1h 8Eh Enable
13-14
IDC Captured Image Sharpen Sig_SHARPEN 658 F1h 92h Enable
13-15
IDC Border Type DocCap_BORDER 829 F2h 3Dh None
13-16
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.
