DataWedge 3 - 37
ADF Example
The following illustrates an example of creating Advanced Data Formatting:
When a user scans a bar code with the following criteria:
• Code 39 bar code.
• length of 12 characters.
• contains 129 at the start position.
Modify the data as follows:
• Pad all sends with zeros to length 8.
• send all data up to character X.
• send a space character.
To create an ADF rule for the above example:
1. Touch > .
2. Touch Profile0.
3. Under Keystroke Output, touch Advanced data formatting.
4. Touch Enable.
5. Touch Rule0.
6. Touch Criteria.
7. Touch String to check for.
8. In the Enter the string to check for text box, enter 129 and then touch OK.
9. Touch String position.
10. Change the value to 0.
11. Touch OK.
12. Touch String length.
13. Change value to 12.
14. Touch OK.
15. Touch Source criteria.
16. Touch Barcode input.
17. Touch All decoders enabled to disable all decoders.
18. Touch Code 39.
19. Touch three times.
20. Touch Actions.
21. Touch and hold on the Send remaining rule until a menu appears.
22. Touch Delete action.
23. Touch .
24. Touch New action.
25. Select Pad with zeros.
26. Touch the Pad with zeros rule.
27. Touch How many.
