A - 6 TC56 Touch Computer Integrator Guide for Android Version 6.0.1
1-Slot Charge Only Cradle Technical Specifications
4-Slot Charge Only Cradle with Battery Charger Technical Specifications
4 GND Ground
5D+ USB Data+
6 Not Used Not Used
7 ID Cradle ID
Table A-4 I/O Connector Pin-Outs
Pin Signal Description
Table A-5 1-Slot Charge Only Cradle Technical Specifications
Item Description
Dimensions Height: 9.9 cm (3.9 in.)
Width: 9.8 cm (3.86 in.)
Depth: 13.3 cm (5.24 in.)
Weight 378 g (13.3 oz.)
Input Voltage 12 VDC
Power Consumption up to 15 watts
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0°C to 40°C (32°F to 104°F)
Humidity 5% to 95% non-condensing
Drop 76.2 cm (30.0 in.) drops to vinyl tiled concrete at room temperature.
Electrostatic Discharge (ESD) +/- 20kV air
+/- 10 kV contact
+/- 10 kV indirect discharge
Table A-6 5-Slot Charge Only Cradle Technical Specifications
Item Description
Dimensions Height: 10.6 cm (4.17 in.)
Width: 48.9 cm (19.25 in.)
Depth: 13.3 cm (5.24 in.)
Weight 2020 g (71.3 oz.)
Input Voltage 12 VDC

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
