2 - 16 TC56 Touch Computer Integrator Guide for Android Version 6.0.1
Figure 2-13 Ethernet Proxy Settings
7. Touch the Enable Http Proxy checkbox to enable proxy settings.
8. In the Proxy hostname field, enter the proxy server address.
9. In the Proxy port field, enter the proxy server port number.
10. In the Bypass proxy for text box, enter addresses for web sites that do not require to go through the proxy
server. Use the separator “|” between addresses.
11. Touch SAVE.
12. Touch .
Configuring Ethernet Static IP Address
The TC56 includes Ethernet cradle drivers. After inserting the TC56, configure the Ethernet connection:
1. Swipe down with two fingers from the status bar to open the quick access panel and then touch .
2. Touch Ethernet.
3. Place the TC56 into the Ethernet cradle slot.
4. Slide the switch to the ON position.
5. Touch .
6. Touch Config.
NOTE When entering proxy addresses in the Bypass proxy for field, do not use spaces or carriage returns
between addresses.
