Zebra TC56 Integrator Guide

TABLE OF CONTENTS
Revision History................................................................................................................................. iii
Table of Contents
About This Guide
Introduction ..................................................................................................................................... xvii
Documentation Set ......................................................................................................................... xvii
Configurations................................................................................................................................. xvii
Software Versions.......................................................................................................................... xviii
Chapter Descriptions ..................................................................................................................... xviii
Notational Conventions.................................................................................................................... xix
Icon Conventions ............................................................................................................................. xix
Related Documents ......................................................................................................................... xix
Service Information.......................................................................................................................... xx
Chapter 1: Getting Started
Introduction .................................................................................................................................... 1-1
Setup .............................................................................................................................................. 1-1
Installing a microSD Card ........................................................................................................ 1-1
Installing the SIM Card ............................................................................................................. 1-4
Installing the Battery ................................................................................................................. 1-7
Charging the Battery ................................................................................................................ 1-7
Charging Indicators .................................................................................................................. 1-8
Replacing the Battery ..................................................................................................................... 1-8
Replacing the microSD Card ....................................................................................................... 1-10
Resetting the TC56 ...................................................................................................................... 1-11
Performing a Soft Reset ......................................................................................................... 1-11
Performing a Hard Reset ....................................................................................................... 1-11

Zebra TC56 Specifications

General

Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	0.016 GB
Internal memory	0.002 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Processor family	Qualcomm
Processor frequency	1.8 GHz
Operating system version	6.0
Operating system installed	Android
RFID reader	-
Certification	WFA (802.11n, 802.11ac, WMM-AC, Voice Enterprise, WMM-PS), Miracast WFA (Mobile AP / Personal Hotspot)
Product color	Black, Silver
Linear (1D) barcodes supported	Code 39
International Protection (IP) code	IP67
Battery capacity	4300 mAh
Data network	CDMA, EDGE, GPRS, GSM, HSPA, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
WCDMA bands supported	850, 1900 MHz
Second camera	No
Rear camera resolution (numeric)	13 MP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	155 mm
Width	75.5 mm
Height	18.6 mm
Weight	249 g
