6.4.2 Creepage distances and clearances
The creepage distances and clearances meet the requirements of the overvoltage category II,
pollution degree 2.
6.4.3 Insulation test voltages, routine test
Parameter Value
Relay circuit against other circuitry 1350 V AC 2 s or
1900 V DC 2 s
24 V circuits against other circuitry 350 V AC 2 s or
500 V DC 2s
COM interfaces, electrically isolated 350 V AC 2 s or
500 V DC 2s
Ethernet 350 V AC 2 s or
500 V DC 2s
6.4.4 Power supply units
For the supply of the modules, power supply units according to PELV specifications must be
used.
6.4.5 Electromagnetic compatibility
Electromagnetic Compatibility
Device suitable for:
Industrial applications Yes
Domestic applications No
Immunity against electrostatic discharge
(ESD):
According to IEC 61000-4-2, zone B, crite-
rion A
Electrostatic voltage in case of air dis-
charge
8 kV
Electrostatic voltage in case of contact dis-
charge
6 kV
ESD with communication connectors In order to prevent operating malfunctions,
it is recommended, that the operating per-
sonnel discharge themselves prior to
touching communication connectors or
perform other suitable measures to reduce
effects of electrostatic discharges.
Immunity against the influence of radiated
(CW radiated):
According to IEC 61000-4-3, zone B, crite-
rion A
Test field strength 10 V/m
According to EN
61131-2
System data AC500-eCo V3 > Electromagnetic compatibility
2021/06/29 3ADR010635, 2, en_US 155
