The user can configure the following input channel as interrupt input.
● Interrupt input 0 : Input Channel 0
● Interrupt input 1 : Input Channel 1
● Interrupt input 2 : Input Channel 2
● Interrupt input 3 : Input Channel 3
E.g. PM50x2-x-xETH with interrupt inputs on digital inputs I0…I3
See also the following chapter:
After configuring the parameter, the user need to create a new task with the “Type” set to
“External” and the “External event” set to “OnBoard_Binary_Input”.
System technology > Use the onboard I/Os as interrupt input with dedicated interrupt task
2021/06/29 3ADR010635, 2, en_US 179
